Tapper 100:1/20 dB 500W 350-5930 MHz 4.3-10F

Orbis PIM -161 dBc @ 2x43 dBm, 100:1 20dB, 500W, frequency 350-5930 MHz, connector 4.3-10F

Product code

3004182

€142.19

In stock 0, Delivery time 28 days from the order if the product is out of stock.

This product is compatible with 3500 MHz frequency, which is used in the 5G mobile network technology. View also our other 5G compatible components for indoor mobile coverage applications>>

Technical details
Manufacturer's product name	DN-04FE 100:1 20dB 500W 350-5930 MHz
Application	Indoor Mobile Coverage, Mobile network
RF connector 1	4.3-10 female
Power (W)	500
PIM (@2x43 dBm)	-161
VSWR	1,25
Frequency range (MHz)	350-5930
Output split (dB)	-0.1/-20.1
Ratio nom. (dB)	100:1/20
5G Compatible	Yes

All prices VAT 0%.
